TY-085 Angled-Shaft Oscillating Motor with Integrated Gear Housing

TY-085 Angled-Shaft Oscillating Motor with Integrated Gear Housing

1. Motor and gear housing in one assembly, no separate swing set needed
2. Angled main shaft suits tilt-type fan heads
3. Ribbed white gear case with greased gear train for quiet sweep
4. Visible copper windings allow quick quality inspection
5. Swing angle, speed taps, shaft and voltage customizable

Details

The TY-085 combines a fan motor and an oscillation gear housing into one compact assembly, and its most noticeable trait is the angled arrangement between the main motor body and the white plastic gearbox on its side. The result is a unit where the swing mechanism is already built in, so the fan maker does not need to source and align a separate gear set. The main shaft projects forward at a slight angle that suits tilt-style fan heads, while the gearbox converts the motor's rotation into the slow side-to-side sweep that spreads air across a room. Designing around this integration shortens production lines: fewer parts, fewer fasteners and fewer alignment checks before the fan head is closed. The metal motor body carries copper-colored windings that remain visible through the frame, which helps inspectors verify winding quality at a glance. The white nylon-type gear case is moulded with ribs to resist deformation, and the gear train runs in grease to keep the sweep quiet and smooth. Because oscillation gears take repeated reversing loads, the teeth are shaped for wear resistance and the case tolerances are kept tight to prevent backlash. The TY-085 suits floor fans, desk fans and tower-style units in the mid-range, particularly designs where the fan head is slim and internal space is at a premium. We can customize swing angle, speed taps, shaft length and the voltage, and we can provide a clutch-type knob if you want users to lock or release the oscillation. For purchasers, the benefit is lower total cost: one purchase order covers both the motor and the oscillation mechanism, and failures from mismatched components are largely eliminated. Ask for a sample and compare its swing smoothness with your existing assembly. Our engineers will gladly review your fan head drawing to confirm the fit.
