TY-090 Slim Laminated-Stack Vertical-Shaft Mini Fan Motor

TY-090 Slim Laminated-Stack Vertical-Shaft Mini Fan Motor

1. Slim stacked-lamination body fits narrow appliance housings
2. Fast start and responsive speed change thanks to low rotor mass
3. Low power use and low heat, suitable for plastic enclosures
4. Output shaft can be knurled, flatted or threaded
5. Wound for 12V, 24V, 110V or 220V; forward or reversible

Details

The TY-090 is a small, upright fan motor whose appearance is defined by its tall stack of laminations, visible as fine horizontal lines around a slender cylindrical body. A short shaft rises from the top, and the compact base allows it to fit into narrow spaces where larger oscillating motors will not. This is the motor for small appliances: desk fans, personal cooling devices, aromatherapy diffusers, rotating display stands, hot-air circulators and miniature ventilation modules. Its modest size does not mean low quality. The stator is assembled from precisely stamped silicon steel sheets, riveted tightly together to prevent buzzing, and the rotor is balanced to run quietly at the speeds typical for small-diameter fan blades. Because the mass is concentrated near the axis, the ty-090 starts quickly and responds well to speed changes, which pleases users who expect immediate airflow when they press the power button. Mounting is through the lower flange, and the output shaft can be knurled, flatted or threaded to suit different blade hubs. Compared with the heavier fan motors in this family, the ty-090 consumes little energy, produces little heat and can be installed in plastic housings without special thermal considerations. Its uncomplicated structure also makes it economical to produce in large quantities, and we maintain stable stock for standard versions. For product developers, the motor is a flexible base: we can wind it for 12V, 24V, 110V or 220V, in single-direction or reversible form, with lead wires of any length. Brands that sell small appliances online will appreciate how consistent the sample and mass-production units are, which cuts down on returns. Let us know your target speed and blade diameter and we will suggest the best winding for your concept.
